9
INSTALLATION
Squeegee
Make sure squeegee adjustment lever is locked in UP
position. Squeegee can be locked in UP position by
raising lever and moving it to the left.
Loosen the two starwheel knobs on the
squeegee assembly. Make sure the black
metal bracket on the squeegee assembly is
aimed forward, toward the concave side of the
squeegee. Lift the squeegee bracket and
washers (if present), and slide the squeegee
assembly onto the rocker plate.
The bracket and washers should rest on top of
the rocker plate, as shown.
