Field Acceptance Test Report
TORNATECH MODEL GPX
WITH OR WITHOUT GPU TRANSFER SWITCH
ELECTRIC FIRE PUMP CONTROLLER
FIELD ACCEPTANCE TEST REPORT
Complete this first section if it was not completed during the Pre-Field Acceptance test
Note: A manual or automatic start must only be executed if the motor and the pump
have been cleared to be started by their respective official service technicians.
YES
NO
1
Place the Normal Power Disconnecting Means handle in the ON position. If a
Transfer Switch is supplied, place the Alternate Power Isolating Switch in the ON
position.
2
Push the START pushbutton. The motor will start.
3
Verify the motor rotation on both normal power and alternate power if applicable.
• If the motor rotation is correct, no adjustment is required.
• To correct the motor rotation, change the motor connection leads 1 and 3 (A and C)
at the run contactor
4
Verify any alarms that would appear on the digital display screen. Correct any alarm
condition.
5
Set the Cut-Out and Cut-In settings by following the ViZiTouch documentation. You
need to be logged in to modify these settings. Verify the automatic start by dropping
the system pressure below the Cut-In setting.
6
Stop the motor by pressing the “STOP” membrane button. Note: the motor will only
stop if the system pressure is above the cut-out setting.
Phase Reversal Verification
YES
NO
1
Verify or simulate phase reversal on both normal and alternate power.
Overcurrent Protection
Controller nameplate info Electric Motor nameplate info
FLC: __________A FLC: __________A
LRC: __________A LRC: __________A
Motor Starts
Normal Power
YES
NO
1
6 manual starts
2
6 automatic starts
3
6 Emergency Handle starts
4
1 remote/deluge valve start
Alternate Power (with GPU Model)
YES
NO
1
6 manual starts
2
6 automatic starts
3
6 Emergency Handle starts
4
1 remote/deluge valve start
Field Settings:
Cut-Out Pressure: ________
Cut-In Pressure: ________
Minimum run period timer activated?
Yes: _____ Set at _____minutes. No: _____
Sequential Start Timer?
Yes: _____ Set at _____seconds. No: _____
