WARNING
Chargingthebatteryproducesgassesthat
canexplode.
Neversmokenearthebatteryandkeepsparks
andamesawayfromit.
Keeptheterminalsandtheentirebatterycaseclean
becauseadirtybatterywilldischargeslowly.Toclean
thebattery,washtheentirecasewithasolutionof
bakingsodaandwater.Rinseitwithclearwater.
Fuses
Thereare8fusesintheelectricalsystem.Thefuse
block(Figure52)islocatedbehindthecontrolarm
accesspanel.
g003988
Figure52
1.Fuseblock
decal117-0169
Figure53
DriveSystem
Maintenance
CheckingtheTorqueofthe
WheelNuts
ServiceInterval:Afterthersthour
Aftertherst10hours
Every250hours
Torquethewheelnutsto94to122N-m(70to90ft-lb).
WARNING
Failuretomaintainpropertorqueofthewheel
nutscouldresultinpersonalinjury.
AdjustingtheTraction
DriveforNeutral
Themachinemustnotcreepwhenthetractionpedal
isreleased.Ifitdoescreep,adjustasfollows:
1.Parkthemachineonalevelsurface,stopthe
engine,andlowerthecuttingunitstotheground.
2.Jackupthefrontofthemachineuntilthe
fronttiresareofftheshopoor.Supportthe
machinewithjackstandstopreventitfrom
fallingaccidentally.
Note:On4-wheel-drivemodels,thereartires
mustalsobeofftheground.
3.Ontherightsideofthehydrostat,loosenthe
locknutonthetraction-adjustmentcam(Figure
54).
42
