Toro 03781TE - Adjusting the Lift-Arm Turnaround Position; Folding the Roll Bar

2.Insertatubeorsimilarobjectontothelong
springendtorelievethespringtensionduring
theadjustment(Figure34).
CAUTION
Thespringsareundertensionandcould
causepersonalinjury.
Usecautionwhenadjustingthesprings.
3.Whilerelievingthespringtension,removethe
boltandlocknutsecuringthespringactuatorto
thebracket(Figure34).
g015078
Figure34
1.Spring2.Springactuator
4.Movethespringactuatortothedesiredhole
locationandsecureitwiththelocknut.
5.Repeattheprocedureontheremainingspring.
AdjustingtheLift-Arm
TurnaroundPosition
1.Parkthemachineonalevelsurface,lowerthe
cuttingunits,engagetheparkingbrake,shutoff
theengine,andremovethekey.
2.Thelift-armswitchislocatedbehindthefront
rightliftarm(Figure35).
g015079
Figure35
1.Switch
3.Loosentheswitchmountingscrews(Figure35)
andmovetheswitchuptoincreasethelift-arm
turnaroundheightormovetheswitchdownto
decreasethelift-armturnaroundheight.
4.Tightenthemountingscrews.
FoldingtheRollBar
Youcanfoldtherollbardowntoallowaccessinto
areasofrestrictedheight.
WARNING
Themachinedoesnothavearollover
protectionsystem(ROPS)whentherollbaris
foldeddownandshouldnotbeconsidered
aROPS.
Donotwearaseatbeltwhentherollbaris
lowered.
1.Parkthemachineonalevelsurface,lowerthe
cuttingunits,engagetheparkingbrake,shutoff
theengine,andremovethekey.
2.Supporttheweightoftheupperframeoftheroll
barwhileremovingthesnappinsandclevispins
fromthepivotbrackets(Figure36).
31
