Toro 03781TE - Checking the Fuses; Servicing the Battery

11.Closetheconsolepanelandsecurethelatch.
ServicingtheBattery
ServiceInterval:Every50hours
Important:Beforeweldingonthemachine,
disconnectthenegativecablefromthebatteryto
preventdamagetotheelectricalsystem.
Note:Checkthebatteryconditionweeklyorafter
every50hoursofoperation.Keeptheterminalsand
theentirebatterycasecleanbecauseadirtybattery
willdischargeslowly.
Cleanthebatteryasfollows:
1.Parkthemachineonalevelsurface,lowerthe
cuttingunits,engagetheparkingbrake,shutoff
theengine,andremovethekey.
2.Removethebatteryfromthemachine.
3.Washtheentirecasewithasolutionofbaking
sodaandwater.
4.Rinsethecasewithcleanwater.
5.Coatthebatterypostsandcableconnectorswith
Grafo112X(skin-over)grease(T oroPartNo.
505-47)orpetroleumjellytopreventcorrosion.
CheckingtheFuses
Thefusesarelocatedundertheoperator’scontrol
panel.
decal125-4605
Figure59
Parkthemachineonalevelsurface,lowerthecutting
units,engagetheparkingbrake,shutofftheengine,
andremovethekey.
Unhookthelatchandraisetheoperator'sconsole
panel(Figure60)toexposethefuses(Figure61).
g200376
Figure60
1.Operator'sconsolepanel
2.Latch
g016642
Figure61
1.Fuses
47
