Toro 03781TE - Changing the Planetary-Gear-Drive Oil

g225612
Figure63
1.Fillplug(12o’clockposition)
2.Checkplug(3o’clockposition)
3.Drainplug(6o’clockposition)
2.Removethecheckplugatthe3o’clockposition
(Figure63).
Theoillevelshouldbeatthebottomofthe
check-plughole.
g225606
Figure64
1.Check-plughole2.Checkplug
3.Iftheoillevelislow,removethellplugatthe
12o’clockpositionandaddoiluntilitbeginsto
owoutoftheholeatthe3o’clockposition.
4.ChecktheO-ringfortheplug(s)forwearor
damage.
Note:ReplacetheO-ring(s)asneeded.
5.Installtheplug(s).
6.Repeatsteps1through5ontheplanetarygear
assemblyattheothersideofthemachine.
Changingthe
Planetary-Gear-DriveOil
ServiceInterval:Aftertherst200hours
Every800hoursoryearly,whichevercomes
rst.
Lubricantspecication:highqualitySAE85W-140
gearlubricant
Planetaryandbrakehousinglubricationcapacity:
0.65L(22oz)
DrainingthePlanetary-Gear-Drive
1.Parkthemachineonlevelsurface,positionthe
wheelsothatthellplugisatthe12o'clock
position,thecheckplugisat3o'clockposition,
andthedrainplugisatthe6o'clockposition;
refertoFigure63inCheckingthePlanetary
Gear-DriveLubricant(page48).
2.Removethellplugatthe12o’clockposition
andthecheckplugatthe3o’clockposition
(Figure65).
g225609
Figure65
1.Drain-plughole
3.Checkplug
2.Fillplug4.Drainplug
3.Placeadrainpanundertheplanetaryhub,
removethedrainplugatthe6o’clockposition,
andallowtheoiltofullydrain(Figure65).
4.ChecktheO-ringsforthell,check,anddrain
plugsforwearordamage.
Note:ReplacetheO-ring(s)asneeded.
5.Installthedrainplugintothedrainholeofthe
planetaryhousing(Figure65).
6.Placeadrainpanunderthebrakehousing,
removethedrainplug,andallowtheoiltofully
drain(Figure66).
49
