Figure15
1.Theoillevelistoolow;
addoiltothecrankcase.
3.Theoilleveliscorrect.
2.Theoillevelistoohigh;
removeoilfromthe
crankcase.
•Iftheoillevelistoolow,slowlypourasmall
amountofoilintotheoil-lltube,wait3minutes,
andrepeatsteps3through5untiltheoillevelis
correctasshowninFigure15.
•Iftheoillevelistoohigh,draintheexcessoiluntil
youobtainthecorrectoillevelonthedipstick.To
draintheexcessoil,refertoChangingtheEngine
Oil(page17).
Important:Iftheoillevelinthecrankcaseistoo
lowortoohighandyouruntheengine,youmay
damagetheengine.
6.Installthedipsticksecurely.
AdjustingtheCuttingHeight
WARNING
Adjustingthecuttingheightmaybringyouinto
contactwiththemovingblade,causingserious
injury.
•Stoptheengineandwaitforallmovingparts
tostop.
•Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
Adjustthecuttingheightasdesired;refertoFigure14and
Figure15.
Note:Toraisethemachine,movethefrontandrear
cutting-heightleversforward;tolowerthemachine,movethe
cutting-heightleversrearward.Setthefrontandrearwheels
tothesameheightunlessspecialcircumstancesrequire
otherwise;refertoOperatingTips(page15).
1
2
3
4
5
6
7
G017634
Figure16
Frontcutting-heightlever
1.A:10.8cm(4-1/4inches)5.E:5.7cm(2-1/4inches)
2.B:9.5cm(3-3/4inches)6.F:4.4cm(1-3/4inches)
3.C:8.3cm(3-1/4inches)7.G:3.2cm(1-1/4inches)
4.D:7.0cm(2-3/4inches)
1
2
3
4
5
6
7
G017635
Figure17
Rearcutting-heightlever
1.A:10.8cm(4-1/4inches)5.E:5.7cm(2-1/4inches)
2.B:9.5cm(3-3/4inches)6.F:4.4cm(1-3/4inches)
3.C:8.3cm(3-1/4inches)7.G:3.2cm(1-1/4inches)
4.D:7.0cm(2-3/4inches)
