Toro 20199 - Initial Setup Tasks; Installing Blade-control Bar; Filling Engine with Oil

1
G016551
Figure4
1.Handle-locklever
2.Releasethehandle-locklever(Figure4).
3.Pullthehandlerearwardandlockitintoposition
(Figure4).
2
InstallingtheBlade-Control
Bar
NoPartsRequired
Procedure
Installtheblade-controlbarintotheupperhandle(Figure5).
Figure5
3
FillingtheEnginewithOil
NoPartsRequired
Procedure
Important:Yourmachine
does not comewithoilin
theengine.Beforestartingtheengine,lltheengine
withoil.
Max.ll:0.59L(20oz),type:SAE30detergentoilwithan
APIserviceclassicationofSF,SG,SH,SJ,SL,orhigher.
Note:Whenthecrankcaseisempty,pourabout3/4of
thecrankcasecapacityofoilinthecrankcase,thendothe
following:
1.Movethemachinetoalevelsurface.
2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure6).
G017514
Figure6
3.Wipethedipstickcleanwithacleancloth.
4.Insertthedipstickfullyintotheoil-lltube,then
removethedipstick.
5.Readtheoillevelonthedipstick(Figure6).
6
