StoppingtheEngine
StandardModel
Pressthetoggleswitch(Figure21)totheStoppositionand
holdituntiltheenginestops.
G017636
Figure21
1.Toggleswitch
Electric-startModel
1.TurnthekeytotheOffposition(Figure22).
G017517
Figure22
2.Whentheenginestops,removetheignitionkeyand
takeitwithyouwhenyouleavethemachine.
EngagingtheBlade
Whenyoustartyourengine,thebladedoesnotturn.You
mustengagethebladetomow.
1.Pulltheblade-control-barlockbacktotheblade-control
bar(Figure23).
g016484
1
2
Figure23
1.Blade-controlbarlock2.Blade-controlbar
2.Slowlypulltheblade-controlbarbacktothehandle
(Figure23).
3.Holdtheblade-controlbaragainstthehandle(Figure
24).
g016485
Figure24
DisengagingtheBlade
Releasetheblade-controlbar(Figure25).
Figure25
Important:Whenyoureleasetheblade-controlbar,
thebladeshouldstopwithin3seconds.Ifitdoesnot
stopproperly,stopusingyourmachineimmediatelyand
contactanAuthorizedServiceDealer.
12
