Toro 2024 User Manual

125-6125
1.Warning—readthe
Operator’sManual.
6.Pressandholdtomove
thedrillcarriageathigh
speedupordownthedrill
frame.
2.Explosionhazard;
electricalshock
hazard—donotdigbefore
callinglocalservices.
7.ModeI—spindrillspindle
clockwise.ModeII—left
triggerpressed,openthe
lowerwrench;lefttrigger
released,raisethepipe
elevator.
3.Presstoapplytread-joint
compound.
8.ModeI—spindrillspindle
counterclockwise.Mode
II—lefttriggerpressed,
closethelowerwrench;
lefttriggerreleased,lower
thepipeelevator.
4.Pressandholdfor
maximumdrillinguid
pressure;releasetostop
theow.
9.Thrustthedrillcarriage
forward.
5.Presstoturnthe
drilling-uidpumpon
oroff.
10.Pullthedrillcarriage
rearward.
125-6126
1.Entanglementhazard—keepawayfrommovingparts.
125-6127
1.Cutting/dismembermenthazard,fan—keepawayfrom
movingparts.
125-6128
1.Highpressureuidhazard,injectionintothebody—read
theOperator’sManualbeforeperformingmaintenance.
