Figure88
1.Fillerneck3.Funnel
2.Oil-llcap
Note:Useafunnelwithaexible,attachedhoseto
directtheengineoilintotheengine.
9.Fillthecrankcasewithapproximately7.5L(8USqt)of
thespeciedengineoil;refertoServicingtheEngine
OilandFilter(page66).
10.Installtheoil-llcap.
11.Starttheengine,runitatidleforabout2minutes,and
checkforoilleaks.
12.Stoptheengineandremovethekey.
13.Waitfor2or3minutesandchecktheoillevel;referto
CheckingtheEngine-OilLevel(page66).
AdjustingtheValveClearance
ServiceInterval:Aftertherst250hours
Every2,000hours
Refertotheengineowner’smanual,includedwiththe
machine,fortheadjustmentprocedure.
Ifyoucannotadjustthevalveclearance,contactyour
AuthorizedToroServiceDealerforvalveadjustment.
ServicingtheSparkArrestor
(IfEquipped)
ServiceInterval:Every250hours—Clearthesparkarrestor
inthemuferofcarbonbuildup.
1.Parkthemachineonalevelsurface,stoptheengine,
andremovetheignitionkey.
2.Removethepipeplugfromtheclean-outportatthe
lowersideofthemufer.
WARNING
Themufermaybehotandcouldcause
injury.
Becarefulnottotouchthehotmufer.
3.Starttheengine.
4.Plugthenormalmuferexitwithablockofwoodor
metalplatesothattheexhaustowwillbeforcedout
oftheclean-outport.Continuetoblocktheexituntil
carbondepositsceasecomingoutoftheport.
WARNING
Donotstandinlinewiththeclean-outport;
hotelementscouldcauseseriousinjury.
Wearsafetyglasses.
5.Stoptheengineandreplacethepipeplug.
