HydraulicSystem
Maintenance
ServicingtheHydraulicFluid
Thehydraulicreservoirislledatthefactorywith
approximately102L(27USgallons)ofhigh-qualityhydraulic
uid.Checkthelevelofthehydraulicuidbefore
theengineisrststartedanddailythereafter.The
recommendedreplacementuidfollows:
ToroPremiumAllSeasonHydraulicFluid(Availablein
5gallonpailsor55gallondrums.ContactyourAuthorized
ToroDealerforpartnumbers.)
Alternateuids:IftheTorouidisnotavailable,other
uidsmaybeusedprovidedtheymeetallthefollowing
materialpropertiesandindustryspecications.Wedonot
recommendtheuseofsyntheticuid.Consultwithyour
lubricantdealertoidentifyasatisfactoryproduct.
Note:Torowillnotassumeresponsibilityfordamage
causedbyimpropersubstitutions,souseonlyproducts
fromreputablemanufacturerswhowillstandbehindtheir
recommendation.
HighViscosityIndex/LowPourPoint
Anti-wearHydraulicFluid,ISOVG46
MaterialProperties:
42.2cStat40°C(104°F) Viscosity,ASTMD445
7.8cStat100°C(212°F)
ViscosityIndexASTM
D2270
158
PourPoint,ASTMD97-6°C(-42°F)
IndustrySpecications:VickersI-286-S(QualityLevel),
VickersM-2950-S(Quality
Level),DenisonHF-0
Note:Manyhydraulicuidsarealmostcolorless,makingit
difculttospotleaks.Areddyeadditiveforthehydraulic
systemoilisavailablein20mL(2/3oz)bottles.Onebottleis
sufcientfor15-22L(4-6gallons)ofhydraulicoil.Orderthe
hydraulicoilfromyourAuthorizedToroDealer.
Note:Ifambientoperatingtemperaturesexceed43°C(110°
F),contactToroforuidrecommendations.
WARNING
Hydraulicuidescapingunderpressurecan
penetrateskinandcauseinjury.
•Ifhydraulicuidisinjectedintotheskinit
mustbesurgicallyremovedwithinafewhours
byadoctorfamiliarwiththistypeofinjury.
Gangrenemayresultifthisisnotdone.
•Keepyourbodyandhandsawayfrompin-hole
leaksornozzlesthatejecthigh-pressure
hydraulicuid.
•Usecardboardorpapertondhydraulicleaks.
•Safelyrelieveallpressureinthehydraulicsystem
beforeperforminganyworkonthehydraulic
system.
•Makesurethatallhydraulic-uidhosesand
linesareingoodconditionandallhydraulic
connectionsandttingsaretightbefore
applyingpressuretohydraulicsystem.
CheckingtheHydraulicFluid
ServiceInterval:Beforeeachuseordaily
Checkthehydraulicuidasfollows:
1.Parkthemachineonalevelsurface,stoptheengine,
andremovetheignitionkey.
2.Wait10minutestoallowtheenginetocoolandthe
hydraulicoiltostabilize.
3.Openthefronthood.
4.Lookatthesightgaugeonthehydraulictankandcheck
theleveloftheoil(Figure108).
