AdjustingtheCarriagePressure
Tohydraulicallyadjustthecarriagepressure,dothefollowing:
1.Pressbutton7onthescreentoturnthecarriage
pressuretotheONposition(green);refertothe
Carriage-PressureScreenintheSoftwareGuideforthis
machine.
2.Increaseordecreasethecarriagepressureasfollows:
•Pressbutton5onthescreentodecreasethe
carriagepressure.
•Pressbutton6onthescreentoincreasethe
carriagepressure.
Note:Thecarriage-pressuregaugewilluctuateupor
downbasedonhowmuchyouincreaseordecrease
thecarriagepressure.
CheckingtheEngine-OilLevel
Beforeyoustarttheengineandusethemachine,check
theoillevelintheenginecrankcase;refertoCheckingthe
Engine-OilLevel(page66)inEngineMaintenance.
CheckingtheCoolingSystem
Beforeyoustarttheengineandusethemachine,checkthe
coolingsystem;refertoCoolingSystemMaintenance(page
77).
CheckingtheHydraulic-FluidLevel
Beforeyoustarttheengineandusethemachine,check
thehydraulicuidlevel;refertoCheckingtheHydraulic
Fluid(page83)inHydraulicSystemMaintenance.
Starting/StoppingtheEngine
Tostarttheengine,completethefollowing:
1.Openthefronthood;refertoOpeningtheFront
Hood(page58).
2.TurnthebatterydisconnectswitchtotheONposition;
refertoBattery-DisconnectSwitch(page30).
3.Closeandlatchthehood.
4.Openthedoorontherearcontrolpanel.
5.TurntheignitionkeytotheRUNposition.
IftheWait-to-Startlightilluminates,waituntilitturns
offbeforeproceeding.
6.TurntheignitionkeytotheSTARTpositionuntilthe
enginestarts,thenreleaseit.
Tostoptheengine,turntheignitionkeytotheOFFposition.
Inanemergency,youcanalsostoptheengineandall
processesbypressingtheENGINE-STOPbuttononeitherthe
drivependantorthecontrolpanel.
DrivingtheMachine
1.Walkaroundthemachinetoensurethatnooneisnear
it.Ensurethatallbystandersareclearoftheareawhere
youwillbemovingthemachine.
2.Connectthedrivependanttotherightreceptacleon
thebottomoftherearcontrolpanel.
3.Withthependantinhand,walkatleast6feettothe
sideofthemachine.Besuretokeepthissafedistance
whenevermovingthemachine.
4.PressandholdtheOPERATOR-PRESENCEbuttonon
thedrivependant.
5.Usethespeedswitchonthependanttoincreaseor
decreasetheenginespeedasdesired.
6.Setthedesiredtravelspeed,usingthespeedswitch.
7.Usethejoysticktomovethemachineasdesired.
Note:Formoreinformationonthedrivependant,refer
toDrivePendant(page28).
LoadingandUnloadingtheMachine
WARNING
Movingamachineofthissizeonatrailerover
publicroadscarriesriskstothosearoundthe
machineifitshouldcomeloose,beinvolvedinan
accident,hitalowhangingstructure,etc.
•Followthetie-downproceduresdescribedin
thissectionwhenmovingthemachine.
•Followalllocaltrafcregulationsgoverningthe
haulingoflargeequipment.Thismanualcannot
adequatelycoveralllawsandsafetyregulations;
itisyourresponsibilitytoknowandfollowthe
lawsandregulationsthatpertaintoyou.
WARNING
Themachinecanslipandfallfromatrailerorramp,
crushinganyonecaughtbeneathitandcausing
seriousinjuryordeath.
•Keepallbystandersawayfromthemachineand
trailer.
•Ensurethatthetrailerandramparenotslippery
andarefreeofice,grease,oil,etc.
•Movethemachineontotherampatslowspeed
withtheengineatslowspeed.
•Ensurethatyouhavethemachinecenteredon
therampandtrailer.
1.Ensurethattherampandthetrailerortruckbedcan
supporttheweightofthemachine.
2.Ensurethattheupperandrearpipe-holderpinsare
installedFigure35.
43
