DeckRemoval(continued)
10.Removethepowerhead.Engine/PowerheadRemoval(page4–5)
11.RWDmodelsonly,removetheRWDfrontheight-of-cutassembly.RWD
FrontHeight-of-CutRemoval(page6–8)
12.AWDmodelsonly,removetheAWDfrontheight-of-cutassembly.AWD
FrontHeight-of-CutRemoval(page6–11)
13.Removetherearheight-of-cutassemblies.RearHeight-of-CutRemoval
(page6–12)
14.AWDmodelsonly,removetheAWDfronttransmission.AWDFront
TransmissionRemoval(page7–17)
15.Removethe3(#10–14)screwssecuringthefrontbumpertothedeck.
Removethebumperfromthedeck.
g361255
Figure124
16.Removethechuteassemblyfromthedeck.ChuteAssemblyRemoval
(page6–20)
DeckInstallation
1.Installthechuteassemblyontothedeck.ChuteAssemblyRemoval(page
6–20)
2.Installthefrontbumpertothedeck,securewith3(#10–14)screws.Torque
thescrewsto3.39±0.34N•m(30±3in-lbs).
