AWDFrontWheelInstallation(continued)
g359882
Figure133
3.InstallthesnapringsecuringthepiniongeartotheLHtransmissionaxle
shaft.RepeatontheRHsideoftheunit.
g359881
Figure134
4.InstalltheLHwheeltotheLHpivotarm,securewiththe(3/8–16inch)
shoulderbolt.T orquetheboltto35±1.69N•m(315±15in-lb).Repeat
ontheRHsideoftheunit.
5.Modelsequippedwithelectricstartonly,connectthebatterybyinstalling
thepositivecablerst,thenthenegativecabletothebattery.Installthefoam
padandbatterycover.Securethebatterycoverwith2(M4.2x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
6.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
