LoaderArm/Attachment-TiltLever
•Totilttheattachmentforward,slowlymovethe
levertotheright(Figure10).
•Totilttheattachmentrearward,slowlymovethe
levertotheleft(Figure10).
•Tolowertheloaderarms,slowlymovethelever
forward(Figure10).
•Toraisetheloaderarms,slowlymovethelever
rearward(Figure10).
•Tolowertheloaderarmstoadetent(oat)
position,pushtheleverfullyforward(Figure10).
Note:Thisallowsattachmentssuchastheleveler
andthehydraulicbladetofollowthecontoursof
theground(i.e.,oat)whengrading.
g029293
Figure10
1.Detent(oat)position
4.Tilttheattachment
rearward.
2.Lowertheloaderarms.5.Tilttheattachment
forward.
3.Raisetheloaderarms.
Bymovingthelevertoanintermediateposition(e.g.,
forwardandleft),youcanmovetheloaderarmsand
tilttheattachmentatthesametime.
Loader-ValveLock
Theloader-valvelocksecurestheloader
arm/attachment-tiltleversothatyoucannotpushit
forward.Thishelpstoensurethatnooneaccidentally
lowerstheloaderarmsduringmaintenance.Secure
theloadervalvewiththelock,inadditiontothe
cylinderlocks,anytimeyouneedtoshutoffthe
machinewiththeloaderarmsraised.RefertoUsing
theCylinderLocks(page26).
Tosetthelock,liftuponitsothatitclearstheholein
thecontrolpanelandswingittotheleft,infrontof
theloader-armlever,pushingitdownintothelocked
position(Figure11).
g029981
Figure11
1.Loaderarm/attachment-tilt
lever
2.Loader-valvelock
Loader-Control-ReferenceBar
Theloader-control-referencebarhelpsstabilizeyour
handwhileoperatingtheloaderarm/attachment-tilt
lever(Figure4).
12
