Setup
Loose Parts
Use the chart below to verify that all parts have been shipped.
Step
Description
Qty.
Use
1
No parts required
–
Remove the shipping bracket and
shipping washers.
Handle assembly
1
Flanged bolt, (3/8 x 1 inch)
4
2
Flange nut, (3/8 inch)
4
Install the handle assembly.
Fuel tank with studs installed
1
Bolt, (5/16 x 7/8 inch)
2
Lock nut, (5/16 inch)
2
Washer, (5/16 inch)
4
Hose clamp
1
Lock washer, (5/16 inch)
2
3
Spring
2
Install the fuel tank.
4
No parts required
–
Check and adjust the shift lever
plate.
Control rods
2
Cotter pin
2
Clevis Pin
2
Washer
2
5
Hairpin cotter pin
2
Install the control rods.
Hairpin cotter pin
2
6
Spacers 6
Install the hairpin cotter pins and
spacers.
Operator’s Manual
1
Engine Operator’s Manual
1
Parts Catalog
1
Safety Video
1
Registration Card
1
7
Oil drain hose
1
Read the Operator’s Manual and
watch the video before operating
the machine.
Note: Deter mine the left and right sides of the mac hine from the nor mal operating position.
11
