Figure 40
1. Fuel shut-off valve 2. Clamp
Replacing the Fuel Filter
R e place the fuel filter after ev er y 200 operating
hours or yearly , whic hev er occurs first.
Nev er install a dir ty filter if it is remo v ed from the
fuel line .
Note: Note ho w the fuel filter is installed.
Note: Wipe up any spilled fuel.
1. Diseng ag e the PTO and set the parking brak e .
2. Stop the engine , remo v e the k ey , and w ait for
all mo ving par ts to stop before lea ving the
operating position.
3. Close fuel shut-off v alv e at fuel tank
( Figure 40 ).
Note: R emo v e the fuel line from the fuel
v alv e that is closest to the engine .
4. Squeeze the ends of the hose clamps tog ether
and slide them a w a y from the filter ( Figure 41 ).
Figure 41
1. Hose clamp 3. Filter
2. Fuel line
5. R emo v e the filter from the fuel lines .
6. Install a new filter and mo v e the hose clamps
close to the filter .
7. Open fuel shut-off v alv e at fuel tank
( Figure 40 ).
8. Chec k for fuel leaks and re pair if needed.
Electrical System
Maintenance
Servicing the Fuse
T he electrical system is protected b y a fuse . It
requires no maintenance . If the fuse blo ws c hec k
component or circuit for malfunction or shor t.
T o re place fuse pull out on the fuse ( Figure 42 )
to remo v e or re place it.
33
