Toro 30318 - Control Rods Installation and Adjustment; Install Control Rods

Figure 10
1. Control rod 3. Blade control bail
2. Upper control bar
4. Cotter pin
2. Mak e sure the rod fittings are equal distance
onto eac h control rod. T he rod fittings should
be appro ximately 3-1/2 inc h (89 mm) from
the star t of the threads for the handles lo w est
position ( Figure 11 ).
3. Slide clevis pins through rod fittings and
mounting holes in idler brac k ets (from outside)
( Figure 11 ). Secure with w ashers and hair pin
cotters ( Figure 11 ).
Note: Mak e sure brak e rod is installed in
front (F) mounting hole in idler brac k et.
Figure 11
1. Control rod and tting 5. Washer
2. 3-1/2 inch (89 mm)
6. Hairpin cotter pin
3. Idler bracket 7. Rod tting
4. Clevis pin 8. Hole F
4. Chec k the g ap betw een upper control bar and
fix ed bar with wheel dri v e fully eng ag ed. Gap
should be appro ximately 1 to 1-1/4 inc h (25-32
mm) ( Figure 12 ).
Note: T he upper control bar and fix ed bar
m ust be parallel when the upper control bar
is in the eng ag ed, dri v e , neutral, or brak e
positions .
5. Chec k the operation. If adjustment is required,
remo v e hair pin cotter , w asher , and clevis pin
securing control rod fitting to idler brac k et.
6. T hread fitting up or do wn on rod until proper
position is attained and install the fitting into
the idler brac k et with clevis pin, w asher , and
hair pin cotter .
Figure 12
1. Control rod 4. Upper control bar
2. Fixed control bar
5. 1 to 1-1/4 inch (25-32 mm)
gap
3. Parking brake lever
6. Fitting
7. Chec k the parking brak e adjustment. R efer to
Chec king the Brak es in the Brak e Maintenance ,
pag e 36 .
15
