downtheunitwhenitisstillhotandavoiddirecting
high-pressureorhighvolumesprayatthebearings.
Thegreasettinglocationsandquantitiesare:
TractionUnit
ServiceInterval:Every50hours
•Brakeshaftpivotbearings(5)(Figure34)
•Tractionpedalpivotbushing(1)(Figure35)
•Frontandrearaxlepivotbushings(2)(Figure36)
•Steeringcylinderballjoints(2)(Figure37)
•Tierodballjoints(2)(Figure37)
•Kingpinbushings(2)(Figure37).
Thetopttingonthekingpinshould
onlybelubricatedannually(2pumps).
Figure34
Figure35
Figure36
Figure37
CenterCuttingUnit
Note:Deckmayhavetoberaisedtoexposethegrease
ttingsforthelatchpivotandthelowerlink.
•Latchpivot(2)(Figure39)
Note:Thelatch(Figure38)mayneedtobe
manuallytrippedtogainaccesstothegreasetting.
Useaprybartocloseandre-openthelatch
34
