5-23
Z Master 7500-D Series Service Manual
March 2018 - Digital Edition
Table of Contents
CHASSIS
Chassis
Seat
Removal
1. Park the machine on a level surface, disengage the PTO, and engage the parking brake. Stop the engine, wait
for all moving parts to stop and remove the key.
2. Slide the seat all the way forward on the adjustment tracks.
3. Tilt seat forward.
4 Disconnect the seat switch from the bottom of the seat. Free seat switch harness from the seat frame.
5. Remove the two front nuts securing the seat frame to the seat isolator. Do not remove the back nuts in this
step.
6. Drop the seat back down to the operator’s position.
7. With the seat latched in the down position, remove the two back nuts securing the seat frame to the seat
isolator.
NOTE: Assistance will be needed to complete next step.
8. Remove the seat.
WARNING
Heavy Object, To Avoid Muscle Strain Or Back Injury,
Use Lifting Aids And Proper Lifting Techniques When
Removing Or Replacing heavy objects.
