StoppingtheEngine
CAUTION
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethemachinewhileitis
unattended.
Alwaysremovetheignitionkeyandsettheparking
brakewhenleavingthemachineunattended,even
ifjustforafewminutes.
Lettheengineidleatslowthrottle(turtle)for60seconds
beforeturningtheignitionswitchoff.
Figure19
Important:Makesurethatthefuel-shutoffvalveis
closedbeforetransportingorstoringthemachine,as
fuelleakagemayoccur.Settheparkingbrakebefore
transporting.Makesuretoremovethekeyasthefuel
pumpmayrunandcausethebatterytolosecharge.
UsingtheSafety-Interlock
System
CAUTION
Ifthesafety-interlockswitchesaredisconnectedor
damaged,themachinecouldoperateunexpectedly,
causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlockswitches
dailyandreplaceanydamagedswitchesbefore
operatingthemachine.
UnderstandingtheSafety-Interlock
System
Thesafety-interlocksystemisdesignedtopreventtheengine
fromstartingunless:
•Theparkingbrakeisengaged.
•Theblade-controlswitch(PTO)isdisengaged.
•Themotion-controlleversareintheNEUTRAL-LOCK
position.
Thesafety-interlocksystemalsoisdesignedtostopthe
enginewhenyoumovethetractioncontrolsfromthelocked
positionwiththeparkingbrakeengagedorifyourisefrom
theseatwhenthePTOisengaged.
TestingtheSafety-InterlockSystem
ServiceInterval:Beforeeachuseordaily
Testthesafety-interlocksystembeforeyouusethemachine
eachtime.Ifthesafetysystemdoesnotoperateasdescribed
below,haveanAuthorizedServiceDealerrepairthesafety
systemimmediately.
1.Sitontheseat,engagetheparkingbrakeandmovethe
blade-controlswitch(PTO)totheONposition.Try
startingtheengine;theengineshouldnotcrank.
2.Sitontheseat,engagetheparkingbrakeandmovethe
blade-controlswitch(PTO)totheOFFposition.Move
eithermotion-controllever(outoftheNEUTRAL-LOCK
position).Trystartingtheengine;theengineshould
notcrank.Repeatforothercontrollever.
3.Sitontheseat,engagetheparkingbrake,movethe
blade-controlswitch(PTO)totheOFFposition,and
movethemotion-controlleverstotheNEUTRAL-LOCK
position.Starttheengine.Whiletheengineisrunning,
releasetheparkingbrake,engagetheblade-control
switch(PTO),andriseslightlyfromtheseat;theengine
shouldstop.
4.Sitontheseat,engagetheparkingbrake,movethe
blade-controlswitch(PTO)totheOFFposition,and
movethemotion-controlleverstoNEUTRAL-LOCK
position.Starttheengine.Whiletheengineisrunning,
centereithermotion-controlleverandmoveitforward
