ChargingtheBattery
WARNING
Chargingthebatteryproducesgassesthatcan
explode.
Neversmokenearthebatteryandkeepsparksand
amesawayfrombattery.
Important:Alwayskeepthebatteryfullycharged
(1.265specicgravity).Thisisespeciallyimportantto
preventbatterydamagewhenthetemperatureisbelow
0°C(32°F).
1.Chargebatteryfor10to15minutesat25to30Aor
for30minutesat10A.
2.Whenthebatteryisfullycharged,unplugthecharger
fromtheelectricaloutlet,thendisconnectthecharger
leadsfromthebatteryposts(Figure52).
3.Installthebatteryinthemachineandconnectthe
batterycables;refertoInstallingtheBattery(page40).
Note:Donotrunthemachinewiththebattery
disconnected;electricaldamagemayoccur.
Figure52
1.Positivebatterypost
3.Red(+)chargerlead
2.Negativebatterypost
4.Black(-)chargerlead
ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequiresno
maintenance,however,ifafuseblowscheckthecomponent
andcircuitforamalfunctionorshort.
Thefusesarelocatedontherightconsolenexttotheseat
(Figure53).
1.Toreplacethefuses,pulloutthefusetoremoveit.
2.Installanewfuse(Figure53).
G017436
Figure53
1.Optionalaccesory—15A
4.Main—25A
2.Charge—25A5.Console
3.PTO—10A
