Toro 74142TE - Adjusting the Motion-Control Damper; Adjusting the Motion-Control Neutral-Lock Pivot

AdjustingtheMotion-Control
Damper
Youcanadjustthetopdampermountingbolttoobtaina
moredesiredmotion-controlleverresistance.SeeFigure70
formountingoptions.
Figure70
RightMotionControlShown
1.Torquethelocknutto22.6N∙M(200in-lb).Theboltmust
protrudepastendoflocknutaftertorque.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
AdjustingtheMotion-Control
Neutral-LockPivot
Youcanadjusttheangednuttoobtainthedesired
motion-controlleverresistancewhenyoumovethemto
theNEUTRAL-LOCKposition.SeeFigure71foradjustment
options.
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesiredfeel.
Note:Formoreresistance,tightentheangednut.
Note:Forlessresistance,loosentheangednut
3.Tightenthejamnut.
Figure71
1.Flangednut2.Jamnut
50
