ReplacingtheHydraulic
Pump-DriveBelt
1.Disengagetheblade-controlswitch(PTO)andsetthe
parkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Removethemowerbelt;refertoReplacingtheMower
Belt(page46).
4.Raisethemachineandsupportitwithjackstands
(Figure64).
5.Removetheclutchstop(Figure63).
g017494
1
Figure63
1.Clutchstop
6.Removetheidlerspringfromthepost(Figure64).
7.Removetheexistingbeltfromthehydraulic-unit-drive
pulleysandtheenginepulley.
8.Installthenewbeltaroundtheenginepulleyandthe
2drivepulleys.
g017437
1
6
2
3
4
5
Figure64
1.Idlerpulley4.Pump-drivebelt
2.Idler-springpost5.Righthydraulic-pump
pulley
3.Enginepulley
6.Lefthydraulic-pumppulley
9.Installtheclutchstop(Figure63).
10.Installthemowerbelt;refertoReplacingtheMower
Belt(page46).
