Toro 74142TE - Adjusting the Anti-Scalp Rollers

AdjustingtheHeight-of-CutPin
Mower-decksize
Height-of-cut
range
Increments
122cm(48inch)
38to127mm
(1-1/2to5inches)
6mm(1/4inch)
Adjusttheheight-of-cutfrom25to140mm(1to
5-1/2inches)in6mm(1/4inch)incrementsbymovingthe
clevispinintodifferentholelocations.
1.MovethetransportlocktotheLOCKposition.
2.Pushonthedeck-liftpedalwithyourfoo,andraisethe
mowerdecktothetransportposition(alsothe140mm
(5-1/2inches)height-of-cutposition)asshownin
Figure24.
3.Toadjust,rotatethepin90degreesandremovethepin
fromtheheight-of-cutbracket(Figure24).
4.Selectaholeintheheight-of-cutbracketcorresponding
totheheight-of-cutdesired,andinsertthepin(Figure
24).
5.Pushonthedecklift,pullbackonthetransportlock,
andslowlylowerthemowerdeck.
Figure24
1.Deck-liftpedal
3.Transportlock
2.Cut-of-heightpin
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,adjusttheheight
oftheanti-scalprollers.
1.Disengagetheblade-controlswitch(PTO),movethe
motion-controlleverstotheNEUTRAL-LOCKposition,
andsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
g017628
Figure25
1.Anti-scalproller4.Flangenut
2.Spacer
5.Bolt
3.Bushing
g017629
Figure26
1.Anti-scalproller3.Flangenut
2.Bushing4.Bolt
23
