AdjustingtheTracking
1.Disengagetheblade-controlswitch(PTO).
2.Drivetoanopen,atareaandmovethemotion-control
leverstotheNEUTRAL-LOCKposition.
3.MovethethrottlemidwaybetweentheFASTandSLOW
positions.
4.Movebothmotion-controlleversforwarduntilthey
bothhitthestopsintheT-slot.
5.Checkwhichwaythemachinetracks.
6.Ifthemachinetrackstotheright,loosentheboltsand
adjusttheleftstopplaterearwardontheleftT-slot
untilthemachinetracksstraight(Figure55).
7.Ifthemachinetrackstotheleft,loosentheboltsand
adjusttherightstopplaterearwardontherightT-slot
untilthemachinetracksstraight(Figure55).
8.Tightenthestopplate(Figure55).
Figure55
Leftcontrollevershown
1.Controllever3.Stopplate
2.Bolt
CheckingtheTirePressure
ServiceInterval:Every50hours/Monthly(whichever
comesrst)
Maintaintheairpressureinthefrontandreartiresat90kPa
(13psi).Uneventirepressurecancauseunevencut.Check
thetireswhentheyarecoldtogetthemostaccuratepressure
reading.
Figure56
CheckingtheWheelLugNuts
ServiceInterval:Aftertherst8hours
Yearly
Checkandtorquethewheellugnutsto122to136N∙m(90
to100ft-lb).
