Motion-Control Levers
Use the motion-control levers to drive the machine forward,
reverse, and turn either direction.
Park Position
Move the motion-control levers outward from the center to
the PARK position when exiting the machine (Figure 21).
Always position the motion-control levers into the PARK
position when you stop the machine or leave it unattended.
Smart Speed™ Control System
Lever
The Smart Speed™ Control-System lever, located below the
operating position, gives you a choice to drive the machine at
3 speed ranges— trim, tow, and mow (Figure 24).
Fuel-Presence Window
You can use the fuel window, located on the left side of the
machine, to verify the presence of fuel in the tank (Figure 7).
g014521
Figure 7
1. Fuel-presence window
Height-of-Cut Lever
The height-of-cut lever works with the foot pedal to lock the
deck in a specic cutting height. Adjust the height of cut only
when the machine is not moving (Figure 6).
Hour Meter
The hour meter records the number of hours when you
are in the seat and the ignition switch is in the ON position
(Figure 8).
g027869
Figure 8
1. Hour meter location behind the seat
Attachments/Accessories
A selection of Toro approved attachments and accessories is
available for use with the machine to enhance and expand
its capabilities. Contact your Authorized Service Dealer or
Distributor or go to www.Toro.com for a list of all approved
attachments and accessories.
12
