Toro Groundsmaster 360 Operator's Manual

g018339
Figure3
1.Wire-harnessconnector
3.PositionthePTOdriveshaftunderthefrontofthe
machine.Ensurethattheslip-shaftyokeofthe
driveshaftispositionedtowardthetransmission
driveshaft(Figure4).
g018340
Figure4
1.Transmissiondriveshaft
4.Locknut
2.Bolt5.Rollpin
3.PTOdriveshaft
4.Alignthesplineandroll-pinholeofthedriveshaft
yokewiththetransmissiondriveshaft.
5.SlidethePTOdriveshaftendyokeontothe
transmissiondriveshaft.
6.SecuretheendyokeofthePTOdriveshaftas
follows:
A.Installtherollpinintheendyokeandshaft.
B.Installtheboltsthroughthedriveshaftend
yoke.
C.Installandtightenthelocknutstosecurethe
endyoketothePTOdriveshaft.
Note:Retaintheremainingbolts,locknuts,
androllpintosecuretheotherendofthe
driveshafttotheattachmentgearboxshaft.
D.Torquethelocknutsto20to25N∙m(175
to225in-lb).
7.LubricatethegreasettingsonthePTO
driveshaft.
8.Afteryouconnecttheotherendofthedriveshaft
totheattachmentgearboxshaft,connect
thewire-harnessconnectortothePTO
solenoid-valve-coilconnector(Figure3).
2
UsingtheOptional
Cutting-Unit-Mounting
Hardware
Partsneededforthisprocedure:
2Retainerpin
2
Greasetting
2
Washerheadscrew(5/16x7/8inch)
Procedure
Note:Thesecomponentsandprocedurearerequired
onlyifacuttingunitthatrequiresretainerpinsis
mountedtothetractionunit.Refertothecuttingunit
Operator’sManualfortheinstallationinstructions.
Note:Ifyouarenotinstallingacuttingunitonthe
tractionunit,removeortieupthe4deck-liftchains
fromtheliftsuspension.
3
AdjustingtheRollBar
NoPartsRequired
Procedure
1.Removethehairpincottersandthepinsfrom
therollbar(Figure5).
2.Raisetherollbartotheuprightpositionand
installthe2pinsandsecurethemwiththe
hairpincotters(Figure5).
Note:Ifyoumustlowertherollbar,pushthebar
forwardtorelievepressureonthepins,remove
thepins,lowerthebarslowly,andsecureitwith
thepinssothatitdoesnotdamagethehood.
12

Toro Groundsmaster 360 Specifications

General

Cutting Width	72 inches
Fuel Type	Diesel
Number of Blades	3
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm) - Zero Turn
Drive System	4WD
Cutting Height	1.5 - 5 inches
