Lynx® SmartHub Installation and User Guide
To Test Radio Communication Between the FIU and the Lynx SmartHub
1. Launch Lynx. See Figure 15.
2. Click the Utilities bar (Figure 15, A).
3. Select the desired satelite from the list (Figure 15, B).
4. Select SmartHub Information radio button (Figure 15, C).
5. Click Start Operations button (Figure 15, D). Certain SmartHub information should be displayed on the screen
(Figure 16). If communication fails, the software will display a “fail” message (Figure 17).
Figure 16
Figure 17
Radio range can vary. Under normal conditions, a range of two miles should be feasible.
To boost radio range, mount radio antennas on masts.
If radio interference is a problem, please see the section below, “Changing the Frequency of the Radio”.
Figure 15
