If the SmartHub has an active running program, the display will read:
P01 Sta01
%00:05:00
(The “%” symbol before the runtime indicates that station 01 is percent adjusted.)
P01 Sta02
00:05:00
(P01 indicates Program 01 is currently active)
P01 Sta03D
00:05:00
(The “D” symbol after the station number indicates that station 03 is disabled.)
P02 Sta10P
00:05:00
(The “P” symbol after the station number indicates that program 02 is paused.)
Man Sta21
00:10:00
(“Man” indicates Manual Watering is currently active)
Man Sta22S
00:10:00
(The “S” symbol after the station number indicates that program 02 is stacked.)
Start Button
Use the Start button to execute either an irrigation program, a Multi-Manual operation, or a Syringe.
These are explained fully in the Manual Watering section, page 31.
Press the Stop button to cancel.
Pause Button
The Pause button can be used to pause any running irrigation program or all irrigation activity.
Stop Button
Use the Stop function to cancel all irrigation (pictured), an active program, an individual station, a manual operation,
or even a switch. If the Lynx SmartHub has no current activity, pressing the Stop button will have no effect. The Stop
function causes a system cancel including power-down / power-up sequence for BOTH daughterboards regardless of
station activity.
Manual : M-Manual
Sat01 001-012 00:05
Simult : 003
Press to start
Manual : Start Prog
Program: 01
Press to start
Manual : Syringe
Runtime: 01 min
Program: 01
Press to start
Pause : Prg: 01
for : 00 hr 05 min
Press to start
00 Programs paused
Cancel : All Watering
Press to Cancel
Running 01 programs
P01 Swh01 00:01:00
Sun 04/02/06 02:31pm
GW# 001-001 Sec: 57
Running 04 prg+ Man
(Running Multi-Manual)
27
Lynx® SmartHub Installation and User Guide
