Menu: Radio Ping For this menu item to work, the radio needs
an address. The radio address is generated
from the Satellite address. The radio within the
satellite and the target radio must be on the
same frequency. The number returned is the
communication time between the radios in ms.
Menu: Radio
Information
Displays information about the installed radio.
Menu: Radio Info.
Model#: RV-M7
Version E28
Serial# 15241181
Last RSSI -dB
Get more: no
Menu: Radio Settings Displays the radio address, power
consumption, and whether RSSI is enabled
or not. RSSI is Received Signal Strength
Indication.
Menu: Radio Settings
Radio Power: 040%
Radio Addr: 1181
RSSI Enable: No
Set Radio Dflts: No
Menu: Radio
Frequencies
Displays the radio’s send and receive
frequencies. The frequencies can be adjusted
from this screen.
Menu: Radio Freq’s
Channel: 1
Rx Freq1 465.5000MHz
Tx Freq1 465.5000MHz
Menu: Message Log Displays the logged messages.
The Message Log history can be cleared from
this screen as well.
Menu: Link Settings View the SmartHub’s communication settings.
A couple of parameters, such as lead time and
whether there is a radio or not, can be edited.
Menu: Link Settings
Lead (On): 030ms
Hang: (Off): 010ms
Baud Rate: 1200
Radio: Digital (Dig)
RSSI Enable: No
36
Lynx® SmartHub Installation and User Guide
