7-4 Power Max Service Manual
AUGER GEARBOX
11. Pull the auger forward a little, slide the pulley from
the auger gearbox input shaft and pull the key out of
the shaft. The auger assembly should pull out to the
front.
Note: If you cannot remove the pulley from the input
shaft, it will be necessary to separate the
auger and traction assemblies to get better
access to the auger pulley. See Separating the
Auger and Traction Assemblies, page 7-4.
12. Slide the bearing off each end of the auger shaft.
If this model has a pivoting scraper, it can now be
removed.
13. Remove the capscrew connecting each auger to
the auger shaft and slide the auger off the shaft
(Fig. 083).
Fig 083 MVC-900XA
14. The auger gearbox is now ready for disassembly
and repair.
Fig 085 MVC-774X
2. Remove the cover over the chute gears. Free the
chute latch cable from its clamp and disconnect the
chute latch cable (Fig. 085).
Fig 084 MVC-771X
Should you be unable to remove the pulley from the
auger gearbox input shaft, it will be necessary to
separate the auger and traction assemblies. After
performing steps 1-7 listed above, proceed as follows:
1. Disconnect the defl ector cable from the defl ector
(Fig. 084).
SEPARATING THE AUGER
AND TRACTION ASSEMBLIES
SECONDARY METHOD
