9-8 Power Max Service Manual
WHEEL CLUTCH
TRACTION DRIVE SYSTEM
Fig 142 MVC-866Xny.jpg
Fig 141 MVC-866XB.jpg
25. Remove retaining ring from both sides of housing
(Fig. 141) and slide the nyliner bushing off the pivot
pulley plate shaft (Fig. 142).
26. Tilt pivot pulley assembly to release the traction belt
tension and remove belt from traction pulley (Fig.
143).
Fig 143 MVC-868X.jpg
Fig 144 MVC-869X.jpg
27. Remove the pivot pulley plate assembly from the
housing (Fig. 144).
