ChoppertoBrushBelt
Toadjustorreinstallthebelt,proceedasfollows:
1.Removethebeltcover(Figure60).
Figure60
1.Choppertobrushbelt
cover
3.Nut
2.Idlerpulley
4.Choppertobrushbelt
2.Loosenthenutontheidlerpulley(Figure60).
3.Slidethebeltoffthechoppershaftandbrushpulley
(Figure60).
4.Rotatethebrushpulleyuntilabrushrowisaligned
withtherotatingcorner(Figure61).
Figure61
1.Brushrow3.Bladetip
2.Rotatingcorner4.Brushhousing
5.Rotatethechopperuntilabladetipisalignedwith
theoutsideofthebrushhousing(Figure61).
6.Carefullyslidethebeltontothechoppershaft.Do
notrotatethechoppershaft.
7.Whiletensioningtherightsideofthebelt,slidethe
bottomofthebeltintothegroovesofthebrush
pulley.Donotrotatethebrushpulley.
8.Whilepushingtheidlerpulleyintothebelt,tighten
thenutontheidlerpulley.
BrushtoRotatingCornerBelt
Totensionthebeltproceedasfollows:
1.Removethebeltcover(Figure62)
2.Loosenthenutontheidlerpulley(Figure62).
Figure62
1.Brushtorotatingcorner
beltcover
3.Idlerpulley
2.Brushtorotatingcorner
belt
4.Nut
3.Pushtheidlerpulleyintothebeltandtightenthe
idlerpulleynutFigure62).
4.Installthebeltcover.
