Toro Reelmaster 3555 - Setup

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Righthoseguide(Models03820and
03821)
1
1
Lefthoseguide(Models03820and
03821)
1
Installthecuttingunits.
2
Nopartsrequired
–
Adjusttheturfcompensationspring.
3
Nopartsrequired
–
Adjustthetireairpressure.
4
Cutting-unitkickstand
1Usethecutting-unitkickstand.
Lockbracket1
Rivet2
Washer1
Screw(1/4x2inches)
1
5
Locknut(1/4inch)
1
Installthehoodlatch(CEmachines).
Yearofproductiondecal
1
CEdecal(PartNo.133-8095)
1
Dangerdecal(PartNo.
138-1186—Models03820and
03821)
1
6
Dangerdecal(PartNo.
121-7928—Model03910)
1
InstalltheCEdecals,ifrequired.
MediaandAdditionalParts
Description
Qty.
Use
Keys2
Starttheengine.
Operator'sManual
1
Engineowner’smanual1
Readthemanualsbeforeoperatingthemachine.
Cuttingperformancepaper
1
Usethepaperforadjustingthecuttingunitreel-to-bedknife
contact.
Shim
1
Usetheshimforadjustingthecuttingunitreel-to-bedknife
contact.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
13
