MOWER DECK
6-23
Toro Timecutter SS/MX/ZS Service Manual
6
4� Carefully rotate the blade so that it is side-to-side
(Fig� 120)�
7� Move to the left side of the machine� Remove the
side carriage bolt (E) and locking nut (D) from the
xedposition(C).Installitintotherearslotted
position (B) (Fig� 121)� Leave the lock nut slightly
loose�
Fig. 120 g.48G014630
A� Blade side-to-side D� Measure from blade tip
B� Sail area of blade to level surface
C� Outside cutting edges
A� Hanger bracket C� Fixed position
B� Slotted adjustment D� Side locking nut
position E� Side carriage bolt
Fig. 121 g.49G015323
5� Measure between the outside cutting edges and the
level surface (Fig� 120)� If both measurements are
not within 3/16” (5mm), an adjustment is required;
continue with this procedure�
6� Support the weight of mower deck by placing wood
blocks under the edges of the deck�
Note: Avoid placing the supports under any anti-
scalp rollers if present on the deck.
A
B
DD
C
A
B
C
D
E
