MOWER DECK
6-24
Toro TimeCutter SS/MX/ZS Service Manual
6
10� When at the desired position, tighten the rear locking
nut on the hanger bracket (Fig� 122)� Tighten the
side locking nut on the hanger bracket�
11� Continue leveling the deck by checking the front-to-
rear blade slope; refer to “Adjusting the Front-to-
Rear Blade Slope” in this chapter
A� 0�25 inch B� 0�125 inch
A� Hanger bracket C� Side locking nut
B� Rear locking nut slotted position
D� Adjustment notches
Fig. 123 g.51G015325
9� Use the notches on the welded bracket to measure
the amount of adjustment� Each notch surface is
equivalent to 0�25”, while a single side is 0�125” (Fig�
123)� Adjust the height of the mower deck to the
desired height�
8� Loosen the rear locking nut (B) on the hanger
bracket just enough to allow the hanger to be
adjusted (Fig� 122)�
Fig. 122 g.50G015324
A
B
C
D
A
B
