MaintenanceService
Interval
MaintenanceProcedure
Yearly
•Changetheenginecoolant(AuthorizedServiceDealeronly).
•Changetheenginecoolant.
Yearlyorbeforestorage
•Checkandadjustthetracktension.
•Touchupchippedpaint.
Every2years
•Drainandcleanthefueltank(s)—AuthorizedServiceDealeronly.
•Replaceallmovinghydraulichoses.
Pre-Maintenance
Procedures
MaintenanceSafety
•Parkthemachineonalevelsurface,disengage
theauxiliaryhydraulics,lowertheattachment,
engagetheparkingbrake(ifequipped),shut
offtheengine,andremovethekey.Waitforall
movementtostopandallowthemachinetocool
beforeadjusting,cleaning,storing,orrepairingit.
•Cleanupoilorfuelspills.
•Donotallowuntrainedpersonneltoservicethe
machine.
•Usejackstandstosupportthecomponentswhen
required.
•Carefullyreleasepressurefromcomponentswith
storedenergy.
•Disconnectthebatterybeforemakinganyrepairs;
refertoUsingtheBattery-DisconnectSwitch(page
34).
•Keepyourhandsandfeetawayfromthemoving
parts.Ifpossible,donotmakeadjustmentswith
theenginerunning.
•Keepallpartsingoodworkingconditionandall
hardwaretightened.Replaceallwornordamaged
decals.
•Donottamperwiththesafetydevices.
•UseonlyToro-approvedattachments.
Attachmentscanchangethestabilityandthe
operatingcharacteristicsofthemachine.Youmay
voidthewarrantyifyouusethemachinewith
unapprovedattachments.
•UseonlygenuineTororeplacementparts.
•Ifanymaintenanceorrepairrequirestheloader
armstobeintheraisedposition,securethearms
intheraisedpositionwiththehydraulic-cylinder
lock(s).
UsingtheCylinderLocks
WARNING
Theloaderarmsmaylowerwhenintheraised
position,crushinganyoneunderthem.
Installthecylinderlock(s)beforeperforming
maintenancethatrequiresraisedloaderarms.
InstallingtheCylinderLocks
1.Removetheattachment.
2.Raisetheloaderarmstothefullyraisedposition.
3.Shutofftheengineandremovethekey.
4.Removethe2pinssecuringthecylinderlockto
thepostsonthesideofthemachine.
5.Slidethecylinderlockoverthelift-cylinderrod
(Figure31).
g031214
Figure31
1.Cylinderlock2.Lift-cylinderrod
6.Repeatstep4and5fortheothersideofthe
machine.
7.Slowlylowertheloaderarmsuntilthecylinder
lockscontactthecylinderbodiesandrodends.
