Toro TX 1000 - Checking the Hydraulic-Fluid Level; Replacing the Hydraulic Filter

IndustryStandards
APIGL-4,AGCOPoweruid821XL,FordNewHolland
FNHA-2-C-201.00,KubotaUDT ,JohnDeereJ20C,Vickers
35VQ25andVolvoWB-101/BM
Note:Manyhydraulicuidsarealmostcolorless,
makingitdifculttospotleaks.Areddyeadditive
forthehydraulicsystemuidisavailablein20ml
(2/3oz)bottles.Onebottleissufcientfor15to
22L(4to6USgallons)ofhydraulicuid.Order
PartNo.44-2500fromyourAuthorizedDealer.
Checkingthe
Hydraulic-FluidLevel
ServiceInterval:Every25hours
Important:Alwaysusethecorrecthydraulic
uid.Unspecieduidswilldamagethehydraulic
system.RefertoHydraulicFluidSpecications
(page45).
1.Removeanyattachments.
2.Parkthemachineonalevelsurface.
3.Raisetheloaderarmsandinstallthecylinder
locks.
4.Shutofftheengineandremovethekey.
5.Openthehoodandsecuretheproprod.
6.Removetherightsidescreen.
7.Cleantheareaaroundthellerneckofthe
hydraulictank(Figure69).
g029748
Figure69
1.Filler-neckcap
8.Removetheller-neckcapandchecktheuid
levelonthedipstick(Figure70).
Note:Theuidlevelshouldbebetweenthe
2notchesofthedipstickwhilethearmsare
loweredoratthelowernotchwhilethearms
areraised.
g029729
Figure70
1.Fillerneck2.Dipstick
9.Ifthelevelislow,addenoughuidtoraiseitto
theproperlevel.
10.Installtheller-neckcap.
11.Installthesidescreen.
12.Closethehood.
13.Removeandstorethecylinderlocksandlower
theloaderarms.
ReplacingtheHydraulic
Filter
ServiceInterval:Aftertherst8hours
Every200hours
Important:Donotsubstituteanautomotiveoil
lter;otherwise,severehydraulicsystemdamage
mayresult.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Openthehoodandsecuretheproprod.
4.Placeadrainpanunderthelterandreplace
thelter(Figure71).
