FuelSystem
Maintenance
DANGER
Incertainconditions,fuelisextremely
ammableandhighlyexplosive.Areor
explosionfromfuelcanburnyouandothers
andcandamageproperty.
RefertoFuelSafety(page15)foracomplete
listoffuelrelatedprecautions.
DrainingtheFuel
Filter/WaterSeparator
ServiceInterval:Beforeeachuseordaily
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Opentherear-accesscover;refertoOpening
theRear-AccessCover(page26).
4.Locatethefuellterontherearsideofthe
engine(Figure47)andplaceacleancontainer
underit.
g029408
Figure47
1.Hoseclamp
3.Fuel-ltercanister/water
separator
2.In-linelter
4.Drainvalve
5.Loosenthedrainvalveonthebottomofthelter
canisterandallowthewatertodrain.
6.Whennished,tightenthedrainvalve.
7.Closetherear-accesscoverandsecurewith
thefastener.
ReplacingtheFuelFilter
CanisterandIn-LineFilter
ServiceInterval:Every400hours
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Opentherear-accesscover;refertoOpening
theRear-AccessCover(page26).
4.Locatethefuelltersontherightsideofthe
engine(Figure47)andplaceacleancontainer
underit.
5.Cleantheareawheretheltercanistermounts
(Figure47).
6.Removetheltercanisterandcleanthe
mountingsurface(Figure47).
7.Lubricatethegasketonthenewltercanister
withcleanoil.
8.Fillthecanisterwithfuel.
9.Installtheltercanisterbyhanduntilthegasket
contactsthemountingsurface,thenrotateitan
additional1/2turn(Figure47).
10.Locatethein-lineltertotheleftofthefuellter
canister(Figure47)andnotethedirectionof
owarrowonthesideofthein-linelter.
11.Opentheclampsoneachendofthein-linelter
andslidethehosesoffit(Figure47).Discard
thelter.
12.Slidethehosesovertheendofanewlter
(Figure47),ensuringthatthearrowonthelter
ispointingtowardtheengineorelectricfuel
pump.
13.Securethehosestothelterwiththehose
clamps.
14.Closetherear-accesscoverandsecurewiththe
fastener(s).
