Toro TX 700 - Page 42

4.Loosentheboltsontherearcoverandremove
thecover.
g366295
Figure56
1.Rearcover
2.Bolt(2)
5.Loosenthejamnutandadjustthetensioning
screwuntilthetrackdeectionis13mm(1/2
inch).
g363401
Figure57
1.Tensioningscrew2.Jamnut
6.Tightenthejamnut.
7.Installthecoverandtightenthebolts.
8.Repeattheprocedurefortheothertrack.
9.Drivethemachine,thenparkthemachineona
levelsurface,engagetheparkingbrake,shutoff
theengine,andremovethekey.
10.Verifythatthetrackdeectionis13mm(1/2
inch).Adjustifnecessary.
ReplacingtheTracks
RemovingtheTracks
1.Removeanyattachments.
2.Parkthemachineonalevelsurface,ensuring
thatonly1sprockethalfisengagedwiththe
track.
g366389
Figure58
1.Sprockethalf
3.Lowertheloaderarms.
4.Shutofftheengineandremovethekey.
5.Raisethemachineoffthegroundsothatthe
bottomofthetrackisatleast10.2cm(4inches)
offtheground.Supportthemachineusingjack
stands.
Note:Usejackstandsratedforyourmachine.
WARNING
Mechanicalorhydraulicjacksmayfailto
supportthemachineandcauseserious
injury.
Usejackstandswhensupportingthe
machine.
6.Loosentheboltsontherearcoverandremove
thecover.
g366295
Figure59
1.Rearcover
2.Bolt(2)
