7.Loosenthejamnutandturnthetensioning
screwtoreleasethetension.
g363401
Figure60
1.Tensioningscrew2.Jamnut
8.Removethesegmentofthedrivesprocketnot
engagedwiththetrack.
Important:Ifyoudonotremovethe
sprocketsegment,itmaybedifcultto
installanewtrackwithoutdamagingit.
g366388
Figure61
1.Bolt(5)2.Sprockethalf
9.Startthemachineanddisengagetheparking
brake.
10.Movethetractioncontrolforwarduntiltheother
halfofthedrivesprocketisnotengagedwith
thetrack
g366387
Figure62
11.Shutofftheengineandremovethekey.
12.Removethetrackfromthetrackframe,drive
hub,thenfrontwheel.
InstallingtheTracks
1.Wrapthenewtrackaroundthefrontwheel.
g366403
Figure63
1.Track
3.Roadwheel(4)
2.Frontwheel4.Rearwheel
2.Pushthetrackunderandbetweentheroad
wheelsandwrapitaroundtherearwheel.
3.Starttheengineanddisengagetheparking
brake.
4.Movethetractioncontrolforwarduntilthedrive
sprockethalfengageswiththetrack.
g366402
Figure64
5.Shutofftheengineandremovethekey.
