INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001A
7. Expansion IO Board: B-SA704-IO-QM-R
5- 2
Installation Procedure
1. Fully open the Ribbon Cover.
2. Slightly open the Top Cover (10 mm).
3. Unlock the Print Head by pressing the hooks toward the center. Then pull the Print Head downward.
NOTE: Care must be taken not to damage the Print Head Element by hitting it against any metal parts.
4. Disconnect the Print Head Cable from the Print Head.
5. Replace the Print Head with a new one, and then reassemble in the reverse order of removal.
Top Cover
Ribbon Cove
r
Print Head
Hook
Print Head Cable
Print Head (B-SA704-TPH3-QM-R)
