Toshiba B-SA4T Series User Manual

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001A
(Revision Date: Jan. 19, 2006)
6. Real Time Clock: B-SA704-RTC-QM-R
6- 3
NOTES: 1. Place the battery with the “+” mark facing up.
2. A new battery is supposed to last about 2 years or more, but it varies depending on the
operating conditions. When a new battery is loaded, write down the battery replacement date
on a supplied battery sticker, and attach it to the reverse side of the Side Panel as a reminder.
4. Attach the Real Time Clock to the printer with the SMW-4x8 screw.
Reverse side of Side Panel
Battery Sticker
Real Time Clock
SMW-4x8 Scre
w

Toshiba B-SA4T Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Speed	Up to 152.4 mm/sec (6 ips)
Max Print Width	104 mm (4.09")
Resolution	300 dpi
Connectivity	USB 2.0
Optional Interfaces	Wireless LAN
Barcodes	UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, Industrial 2 of 5, Postnet, RM4SCC, KIX-Code
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code, Micro PDF417, Aztec Code
Media Thickness	0.06 – 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Length	Up to 300 m
Weight	15 kg
