Toshiba B-SA4T Option Installation Manual

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001A
(Revision Date: Feb. 25, 2008)
8. RFID Module: B-SA704-RFID-U2-EU-R
8- 2
• Packing List
All the following parts are supplied with the kit. Make sure you have all items shown below.
Parts (Quantity) Parts (Quantity) Parts (Quantity)
Antenna Ass’y (1 pc.)
RFID Module (1 pc.)
Antenna Cable (1 pc.)
Interface Cable (1 pc.)
Shield Sheet (for the use of short-pitch
tags) (1 pc.)
RFID Module Attaching Plate (1 pc.)
Cable Clamp (1 pc.)
Edge Guard (Long and short: 2 pcs.
each)
Installation Manual (1 copy)
Tapping Screw M-3x8 (3 pcs.)
Double Sems Screw M-3x6 (2 pcs.)
