INSTALLATION PROCED
URE
FOR OPTIONAL EQUIPMENT
EO15-33001A
1. Cutter Module
1- 5
3.
Mount the Cutter Module Cover by in
serting the hinge pins into the hinges.
4.
Fit the Cutter Unit to the front of the printer
by inserting the Hinge Pins into the Hinge Pin Holes.
5.
Close the Cutter Unit and secure it
to the printer with the Set Screw.
Cutter Module Cove
r
Hinge
Cutter Unit
Hinge Pin
Hinge Pin
Hinge Pin Hole
Hinge Pin Hole
Cutter Unit
Set Screw
6
8
Table of Contents
Default Chapter
2
Table of Contents
2
1 Cutter Module
3
B-Sa204-Qm/ B-Sa204-Qm-R
3
B-Sa204P-Qm-R
6
2 Strip Module
9
B-Sa904-H-Qm-R
9
B-Sa904P-H-Qm-R
16
3 Wireless LAN Module: B-SA704-WLAN-QM
20
4 Serial Interface Board: B-SA704-RS-QM-R
26
Installation Procedure
31
5 300 Dpi Print Head Kit: B-SA704-TPH3-QM-R
32
6 Real Time Clock: B-SA704-RTC-QM-R
32
7 Expansion I/O Board: B-SA704-IO-QM-R
38
Packing List
38
8 RFID Module: B-SA704-RFID-U2-EU-R
41
Applicable Model
41
