2
-EN
Central Control Device (Touch Screen Controller) Installation Manual
Contents
1 Precautions for safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3-1. Installation of Main Unit Box and Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3-1-1. When Installing from the Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3-1-2. When Installing from the Rear. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3-2. Attaching the Power Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3-3. Power, Signal, and Earth Line Connections . . . . . . . . . . . . . . . . . . . . . . . . . . 11
•Thank you for purchasing the system controller.
•Please read this installation manual carefully before installation, and perform the work only in the correct manner.
To Next Page
