Toshiba MW24F11 Service Manual

GENERAL SPECIFICATIONS
G-1 TV CRT CRT Size / Visual Size 24 inch / 600.0mmV
System CRT Type Flat
Magnetic Field BV/BH +0.45G / 0.18G
Color System NTSC
Speaker 2 Speaker
Position Front
Size 1.8 x 3.9 Inch
Impedance 8 ohm
Sound Output MAX 1.5W + 1.5W
10%(Typical) __
G-2 VCR System VHS Player / Recorder
System Video System NTSC
Hi-Fi STEREO Yes
NTSC PB -
Deck OVD-7
Heads Video Head 4 Heads
FM Audio Head 2 Heads
Audio /Control Mono /Yes
Erase(Full Track Erase) Yes
Tape Rec PAL -
Speed NTSC SP/SLP(EP)
Play PAL -
NTSC SP/SLP(EP)
Fast Forward / Rewind Time (Approx.) at 25oC FF:1'48"/REW:1'48"
with Cassette T-120
Forward/Reverse NTSC or PAL-M SP/SLP(EP)=3x,5x / 9x,15x
Picture Search
Frame Advance Yes
Slow Speed 1/10
G-3 DVD System Color System NTSC
Disc DVD, CD-DA, CD-R/RW, Video CD
DVD-R/RW (Video Format Only)
Disc Diameter 120 mm , 80 mm
Drive DM3PA
Search speed Fwd 4 step
Actual 2-120 times(DVD, VIDEO CD)
4-40 times (CD)
Rev 4 step
Actual 2-120 times(DVD, VIDEO CD)
4-40 times (CD)
Slow speed Fwd 1/7 - 1/2 times
Actual --
Rev --
Actual --
G-4 Tuning Broadcasting System US System M
System Tuner and System 1 Tuner
Receive CH Destination US(w/CABLE)
CH Coverage 2~69, 4A, A-5~A-1, A~I, J~W, W+1~W+84
Intermediate Picture(FP) 45.75MHz
Frequency Sound(FS) 41.25MHz
FP-FS 4.5MHz
Preset CH
No
Stereo/Dual TV Sound US-Stereo
Tuner Sound Muting Yes
A3-1

Toshiba MW24F11 Specifications

General

Brand	Toshiba
Model	MW24F11
Category	TV DVD Combo
Language	English
