CHASSIS REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
300 AE006988 A5T7016420A DECK ASSY A5T7016420A
301 AE005514 85OA400245 PINCH ROLLER BLOCK VA2
302 BZ710682 85OA500026 AHC ASS'Y
303 BZ710193 85OP200290 BELT,CAPSTAN (S)
304 BZ710515 85OP600581 WORM
305 AE005919 85OP500091 BASE,AC HEAD
306 BZ710112 85OP800324 SPRING,AC HEAD
307 AE005835 85OA000528 MAIN CHASSIS ASS'Y
308 BZ710517 85OA200089 CLUTCH ASS'Y
309 AE005920 85OA200092 ARM IDLER ASS'Y
310 AE005836 85OA300068 LOADING ARM S UNIT
311 AE005837 85OA300070 LOADING ARM T UNIT
312 BZ710521 85OA400223 INCLINED BASE T UINT 3S
313 AE005838 85OA400249 P5 ARM ASS'Y 2
314 AE005839 85OA400248 TENSION ARM ASS'Y 2
315 BZ710524 85OA400231 INCLINED BASE S UNIT
316 AE005840 85OA900234 CASS HOLDER ASS'Y
317 BZ710552 85OP900745 CASS,OPENER
318 BZ710106 85OP700035 REFLECTOR,LED
319 AE005841 85OP900755 BRACKET,TOP 3V
320 AE004275 85OP400549 HOLDER,CAPSTAN
321 AE005842 85OA900233 LINK UNIT
322 BZ710531 85OP000496 POST,CASS GUIDE
323 BZ710532 85OP200316 REEL,S (S)
324 BZ710533 85OP200317 REEL,T (S)
325 BZ710534 85OP200308 GEAR,IDLER
326 BZ710535 85OP200311 GEAR,CLUTCH
327 BZ710536 85OP200312 GEAR,COUPLING
328 BZ710537 85OP200313 LEVER,CLUTCH
329 BZ710538 85OP300194 GEAR,MAIN LOADING
330 BZ710092 85OP400490 LEVER,TENSION
331 BZ710093 85OP400492 HOLDER,TENSION
332 BZ710366 85OP400520 CAP.P4
333 BZ710762 85OP400542 BAND,TENSION
334 BZ710540 85OP400533 CONNECT,TENSION
335 BZ710541 85OP600573 ARM,BRAKE T
336 BZ710763 85OP600584 BAND,BRAKE T
337 BZ710543 85OP600577 CAM,PINCH ROLLER
338 BZ710544 85OP600578 CAM,MAIN
339 AE005843 85OP600585 ROD,MAIN
340 BZ710546 85OP600582 GEAR,JOINT
341 BZ710110 85OP800322 SPRING,TENSION
342 BZ710547 85OP800360 SPRING,BRAKE T
343 BZ710548 85OP800355 SPRING,COUPLING
344 BZ710549 85OP800356 SPRING,RING
345 AE005844 85OP900754 LEVER,LINK
346 BZ710551 85OP900744 LEVER,FLAP
501 AE005845 810722680U SCREW,TAP TITE(S) BIND M2.6x8
502 AE005846 83ETW3000U E-RING 3.0
503 AE005847 810722640U SCREW,TAP TITE(S) BIND M2.6x4
504 AE005848 810212060U SCREW,PAN M2x6
505 AE005849 810912660U SCREW,TAP TITE(B) PAN M2.6x6
506 AE005850 810A13040U SCREW/WASHER(A) M3x4
507 AE005851 810A12650U SCREW/WASHER(A) M2.6x5
508 BZ710056 82Q264713N POLYSLIDER WASHER 2.6x4.7xT0.13
509 BZ710054 82P184505N POLYSLIDER WASHER(CUT) 1.8x4.5xT0.5
510 AE005540 810722660U SCREW,TAP TITE(S) BIND 2.6x6
CD1501 BZ614292 122H071704 CORD JUMPER 2H071704
CD1502 AD301953 122Y021002 CORD JUMPER 2Y021002
H5001 AD301675 1523Q91003 HEAD (AUDIO CONTROL) VTR-1X2RPE22-756
H5002 AD301676 1543Q02014 HEAD (FULL ERASE) VTR-1X2ERS11-154
! M101 AE005552 1596S98002 MOTOR,LOADING MDB2B66B
! M2001 AE005853 1510S98044 CAPSTAN DD UNIT F2QVB73B
M2003 AE006792 1589S11025 MICRO MOTOR I20AL34K
! UN4001 AE006989 A5T7016500 CYLINDER UNIT ASS'Y A5T7016500
J2-1
To Next Page
